Siemens 7MF1567-3CD00-1AA1 pressure transmitter

The P220 series pressure transmitter is used to measure the pressure of gases, liquids, and vapors.
Stainless steel measuring unit, fully welded
Measurement range 2.5 to 600 bar
Suitable for applications in the fields of high pressure and compression technology
Siemens 7MF1567-3CD00-1AA1 pressure transmitter

advantage
High measurement accuracy
Durable stainless steel casing
High overvoltage and load resistance capability
Used for measuring corrosive and non corrosive media
Used for measuring the pressure of gases, liquids, and vapors
compact design
No need for sealing rings
■ Application
The P220 series pressure transmitter used for measuring pressure is suitable for the following industrial fields:
Mechanical Engineering
shipbuilding
Power Engineering
chemical industry
water supply
design
Non explosion proof structural design
The pressure transmitter is mainly composed of a silicon pressure measuring element with a diaphragm installed inside a stainless steel housing
Cheng. Can use electrical connections that comply with EN 175301-803-A (IP65), with circular plug connections
M12 port (IP67), cable connection (IP67) or quick threaded cable connection (IP67). lose
The output signal is 4... 20 mA or 0... 10 V.
Explosion proof structural design
The pressure transmitter is mainly composed of a silicon pressure measuring element with a diaphragm installed inside a stainless steel housing
Cheng. Can use EN 175301-803-A (IP65) or circular socket M12 (IP67)
Electrical connections. The output signal is 4... 20 mA.
■ Function
Pressure transmitters are used to measure the pressure and liquid level of gases and liquids.
working method
SITRANS P220 pressure transmitter (7MF1567-...), functional diagram
The stainless steel measuring element is equipped with a thin film resistance bridge, and the working pressure is transmitted through the stainless steel diaphragm
come here.
The output voltage of the measuring component is converted into an output current of 4... 20 mA by the preamplifier
Output voltage 0... 10 V DC.
The linearity of the output current is proportional to the input pressure.
Selection and ordering data -7ML1567
SITRANS P220 series pressure transmitter, gauge pressure measurement, suitable for high pressure and compressor applications, fully welded design
Accuracy 0.25% (typical)
Material of liquid receiving components: stainless steel
Non liquid contact component material: stainless steel
The commonly used models are as follows:
7MF1567-3DE01-1AA1 7MF1567-3DE00-1AA1 7MF1567-3CB00-1AA1 7MF1567-3DA00-A1 7MF1567-3BG00-1AA1 7MF1567-3DB00-1AA1

7MF1567-3CA00-1AA1 7MF1567-3DA00-1AA1 7MF1567-3CA00-5FA1 7MF1567-3DD00-1AA1 7MF1567-3DD01-1AA1 7MF1567-3CD00-1AA1
